Highly reliable performance
Hyperscale SATA model
Maximise total cost of ownership savings
Proven helium side-sealing weld technology
Digital environmental sensors
Data protection and security

Market-leading 18 TB HDD offering the highest capacity available for more petabytes
per rack

Highly reliable performance with enhanced caching, making it the logical choice for
cloud data centre and massive scale-out data centre applications

Hyperscale SATA model tuned for large data transfers and low latency

PowerBalance™ feature optimises Watts/TB

Maximise total cost of ownership savings through lower power and weight with
helium sealed-drive design

Proven helium side-sealing weld technology for added handling robustness and
leak protection

Digital environmental sensors to monitor internal drive conditions for optimal
operation and performance

Data protection and security — Seagate Secure™ features for safe, affordable, fast
and easy drive retirement

Proven enterprise-class reliability backed by 5-year limited warranty and 2.5M-hr
MTBF rating

Features
Mean time between failures (MTBF)	2500000 h
HDD sustained transfer rate	270 MiB/s
HDD interface transfer rate	12 Gbit/s
Hot-swap	Yes
Component for	Disk array
Type	HDD
Interface	SAS
HDD size	3.5"
HDD speed	7200 RPM
HDD capacity	14 TB

Power
Operating voltage	5 / 12 V
Power consumption (read)	9.1 W
Power consumption (write)	9.1 W
Power consumption (typical)	5 W

Operational conditions
Non-operating shock	200 G
Operating shock	50 G
Non-operating vibration	2.27 G
Operating temperature (T-T)	5 - 60 °C

Weight & dimensions
Weight	650 g
Height	26.1 mm
Depth	147 mm
Width	101.8 mm

Packaging data
Quantity per pack	20 pc(s)

Logistics data
Harmonized System (HS) code	84717050

leaflet
